A developer's guide to monetizing AI agents with the Nevermined x402 Express middleware

If you've built an AI agent with Express.js, you've probably struggled with the payment problem. How do you:

• Charge users per request?
• Verify they have credits before executing expensive AI calls?
• Track usage and settle payments?
• Handle all the edge cases (expired tokens, insufficient balance, failed settlements)?

The traditional approach involves dozens of lines of boilerplate: checking auth headers, calling payment APIs, wrapping everything in try/catch blocks, and hoping you didn't miss an edge case.

What if you could do it in one line?

Introducing paymentMiddleware

The @nevermined-io/payments package now includes an Express middleware that handles the entire x402 payment flow:

import { paymentMiddleware } from "@nevermined-io/payments/express";


app.use(
 paymentMiddleware(payments, {
   "POST /ask": { planId: process.env.NVM_PLAN_ID!, credits: 1 },
 })
);

‍

That's it. Your /ask endpoint is now payment-protected.

What the Middleware Does

When a request comes in without a payment token:

POST /ask HTTP/1.1
Content-Type: application/json


{"query": "What is the meaning of life?"}

‍

The middleware returns a 402 Payment Required with the payment-required header:

HTTP/1.1 402 Payment Required
payment-required: eyJ4NDAyVmVyc2lvbiI6MiwuLi59


{"error": "Payment Required"}

‍

When the client retries with an x402 token in the payment-signature header:

POST /ask HTTP/1.1
Content-Type: application/json
payment-signature: eyJ4NDAyVmVyc2lvbiI6MiwuLi59


{"query": "What is the meaning of life?"}

‍

The middleware:

• Verifies the token with the Nevermined Facilitator
• Calls your route handler
• Settles the payment (burns credits)
• Returns a settlement receipt in the payment-response header

Your route handler never sees the payment logic—it just processes the request.

Complete Example

Here's a fully working AI agent with payment protection:

// src/agent.ts
import express from "express";
import OpenAI from "openai";
import { Payments } from "@nevermined-io/payments";
import { paymentMiddleware } from "@nevermined-io/payments/express";


const app = express();
app.use(express.json());


// Initialize services
const payments = Payments.getInstance({
 nvmApiKey: process.env.NVM_API_KEY!,
 environment: "sandbox",
});


const openai = new OpenAI({ apiKey: process.env.OPENAI_API_KEY });


// Add payment protection
app.use(
 paymentMiddleware(payments, {
   "POST /ask": { planId: process.env.NVM_PLAN_ID!, credits: 1 },
 })
);


// Your route handler - no payment logic needed!
app.post("/ask", async (req, res) => {
 const { query } = req.body;


 const completion = await openai.chat.completions.create({
   model: "gpt-4o-mini",
   messages: [{ role: "user", content: query }],
 });


 res.json({ response: completion.choices[0]?.message?.content });
});


// Health check (not payment-protected)
app.get("/health", (req, res) => res.json({ status: "ok" }));


app.listen(3000, () => console.log("Agent running on http://localhost:3000"));

‍

Route Configuration Options

Fixed Credits‍

Charge the same amount for every request:

paymentMiddleware(payments, {
 "POST /ask": { planId: PLAN_ID, credits: 1 },
 "POST /generate-image": { planId: PLAN_ID, credits: 10 },
});

‍

Dynamic Credits

Calculate credits based on the request or response:

paymentMiddleware(payments, {
 "POST /generate": {
   planId: PLAN_ID,
   credits: (req, res) => {
     // Charge based on token count in response
     const tokens = res.locals.tokenCount || 100;
     return Math.ceil(tokens / 100);
   },
 },
});

‍

Path Parameters

Works with Express route patterns:

paymentMiddleware(payments, {
 "GET /users/:id": { planId: PLAN_ID, credits: 1 },
 "POST /agents/:agentId/task": { planId: PLAN_ID, credits: 5 },
});

‍

Middleware Options

Customize behavior with options:

paymentMiddleware(payments, routes, {
 // Custom token header(s)
 tokenHeader: "payment-signature",


 // Hook before verification
 onBeforeVerify: (req, paymentRequired) => {
   console.log(`[Payment] Verifying request to ${req.path}`);
 },


 // Hook after settlement
 onAfterSettle: (req, creditsUsed, settlement) => {
   console.log(
     `[Payment] Settled ${creditsUsed} credits, tx: ${settlement.txHash}`
   );
 },


 // Custom error handler
 onPaymentError: (error, req, res) => {
   console.error(`[Payment] Error: ${error.message}`);
   res.status(402).json({ error: error.message });
 },
});

‍

Client Implementation

Here's how clients interact with your payment-protected API:

// src/client.ts
import { Payments } from "@nevermined-io/payments";
import { X402_HEADERS } from "@nevermined-io/payments/express";


const payments = Payments.getInstance({
 nvmApiKey: process.env.NVM_API_KEY!,
 environment: "sandbox",
});


async function callProtectedAPI() {
 const SERVER_URL = "http://localhost:3000";


 // Step 1: Request without token → 402
 const response1 = await fetch(`${SERVER_URL}/ask`, {
   method: "POST",
   headers: { "Content-Type": "application/json" },
   body: JSON.stringify({ query: "What is 2+2?" }),
 });


 if (response1.status === 402) {
   // Step 2: Decode payment requirements
   const paymentRequired = JSON.parse(
     Buffer.from(
       response1.headers.get(X402_HEADERS.PAYMENT_REQUIRED)!,
       "base64"
     ).toString()
   );


   const { planId, extra } = paymentRequired.accepts[0];
   const agentId = extra?.agentId;


   // Step 3: Generate x402 token
   const { accessToken } = await payments.x402.getX402AccessToken(
     planId,
     agentId
   );


   // Step 4: Request with token → 200
   const response2 = await fetch(`${SERVER_URL}/ask`, {
     method: "POST",
     headers: {
       "Content-Type": "application/json",
       [X402_HEADERS.PAYMENT_SIGNATURE]: accessToken,
     },
     body: JSON.stringify({ query: "What is 2+2?" }),
   });


   const data = await response2.json();
   console.log("Response:", data.response);


   // Step 5: Decode settlement receipt
   const settlement = JSON.parse(
     Buffer.from(
       response2.headers.get(X402_HEADERS.PAYMENT_RESPONSE)!,
       "base64"
     ).toString()
   );
   console.log("Credits used:", settlement.creditsRedeemed);
 }
}


callProtectedAPI();

‍

x402 Headers Reference

Environment Setup

# .env
NVM_API_KEY=nvm:your-api-key
NVM_ENVIRONMENT=sandbox
NVM_PLAN_ID=your-plan-id
OPENAI_API_KEY=sk-your-openai-api-key
PORT=3000

Installation

npm install @nevermined-io/payments express

‍

For TypeScript:

npm install -D typescript @types/express @types/node tsx

‍

Running the Example

# Terminal 1: Start the agent
npx tsx src/agent.ts


# Terminal 2: Run the client
npx tsx src/client.ts

‍

Under the Hood

The middleware implements the x402 HTTP transport spec:

• Request matching: Uses path-to-regexp to match routes
• Token extraction: Reads from payment-signature or x-payment header
• Verification: Calls payments.facilitator.verifyPermissions()
• Route execution: Calls next() to let your handler run
• Settlement: Calls payments.facilitator.settlePermissions()
• Response headers: Sets payment-response with settlement receipt

The middleware wraps res.json() and res.send() to ensure settlement happens after your response is ready but before it's sent to the client.

Error Handling

Advanced: Manual Integration

If you need more control than the middleware provides, you can implement the flow manually:

import { Payments } from "@nevermined-io/payments";
import { X402_HEADERS } from "@nevermined-io/payments/express";


app.post("/ask", async (req, res) => {
 const x402Token = req.headers["payment-signature"] as string;


 if (!x402Token) {
   // Return 402 with payment requirements
   const paymentRequired = {
     x402Version: 2,
     error: "Payment required",
     accepts: [
       {
         scheme: "nvm:erc4337",
         network: "eip155:84532",
         planId: process.env.NVM_PLAN_ID,
         extra: { version: "1" },
       },
     ],
     extensions: {},
   };
   res.set(
     X402_HEADERS.PAYMENT_REQUIRED,
     Buffer.from(JSON.stringify(paymentRequired)).toString("base64")
   );
   return res.status(402).json({ error: "Payment Required" });
 }


 // Verify
 const verification = await payments.facilitator.verifyPermissions({
   x402AccessToken: x402Token,
   maxAmount: BigInt(1),
 });


 if (!verification.success) {
   return res.status(402).json({ error: "Verification failed" });
 }


 // Execute workload
 const result = await generateAIResponse(req.body);


 // Settle
 const settlement = await payments.facilitator.settlePermissions({
   x402AccessToken: x402Token,
   maxAmount: BigInt(1),
 });


 // Return response with settlement receipt
 res.set(
   X402_HEADERS.PAYMENT_RESPONSE,
   Buffer.from(
     JSON.stringify({
       success: true,
       creditsRedeemed: 1,
       transactionHash: settlement.txHash,
     })
   ).toString("base64")
 );


 res.json({ result });
});

‍

Resources

Complete Tutorial: http-simple-agent on GitHub
Express Integration Guide: Nevermined Docs
x402 Protocol Spec: x402 on GitHub
Nevermined x402 Spec: x402 Smart Accounts

Questions? Join us on Discord or open an issue on GitHub.
